2010-2012 Subaru Legacy and Outback Navigation Radio Harness with RCA Outputs - Pioneer

Item Number: AHH-70-7552P-RCA

For 2010-2012 Subaru Legacy and Outback models with the factory DVD navigation radio - the flip-up screen with MAP and DEST buttons. These cars also carry the Harman Kardon amplifier.

This is our 20-pin direct wire adapter built with two additions the standard version does not have: RCA outputs to feed the factory amplifier cleanly, and the amplifier turn-on wire (these cars switch the amplifier on through pin 23 of the 24-pin connector). The steering wheel button wiring is built in.

This version terminates for a Pioneer head unit.

Pioneer head units also need the Axxess AXSWC-2 interface box to read the factory steering wheel buttons. Sony and ATOTO head units do not.

No AM/FM antenna adapter is included. These cars use the extended 18-inch antenna adapter (AHH-SUBANT-18) - add it to your order separately.

Built to order. Tell us your year, model and new head unit above and we will wire it to match. Not sure which factory radio you have? Identify it from pictures here.

Purchase:

Price: $51
